Thinkpad T440s Ram Slots

admin

The Lenovo T440s 20AQ005QUS has many exciting features for users of all types. See the Lenovo T440s 20AQ005QUS gallery images above for more product views. FactoryOutletStore stocks a full line of accessories like AC Adapter, Bluetooth Keyboard, and ThinkPad90W AC Adapter SlimTip for the Lenovo T440s 20AQ005QUS. I have a T440s with 4GB RAM soldered to the board and 4GB in a slot. I found out I can replace the 4GB module in the slot with a 8GB module. ↳ ThinkPad T400. Open the latches on both sides of the slot at the same time, and then remove the memory module Save the removed memory module for future use. Place the notched end of the new memory module toward the contact edge side of the memory slot, and insert the memory module into the slot at an angle of about 20 degrees.

Thinkpad t440 soldered ram? A little off tipic. Does anyone know if the t440 with i5 has soldered memory or not? Some models only have one DIMM slot (mine, for. What does the T440 have inside: a) 1 DIMM slot + either 4 or 0 GB RAM soldered. So if you have single 8GB RAM stick - you are on max RAM already. If you have a 4 GB stick installed, then you can swap it for an 8GB to get 12 GB RAM.

  • 1ThinkPad T440s

ThinkPad T440s

This page gives an overview of the ThinkPad T440s.

Machine Type

  • 20AQ, 20AR

Standard Features

  • One of the following processors:
    • 4th Gen Intel® Core™ i5-4210U (Up to 2.60 GHz, 3MB L3, 1600 MHz FSB)
    • 4th Gen Intel® Core™ i5-4210U (Up to 2.70 GHz, 3MB L3, 1600 MHz FSB)
    • 4th Gen Intel® Core™ i5-4300U (Up to 2.90 GHz, 3MB L3, 1600 MHz FSB)
    • 4th Gen Intel® Core™ i7-4600U (Up to 3.30 GHz, 4MB L3, 1600 MHz FSB)
  • The following graphics adapter options:
    • Intel® HD Graphics 4400 (Supports HDMI 1.4 and DisplayPort 1.2, ref: https://software.intel.com/en-us/articles/quick-reference-guide-to-intel-processor-graphics)
    • Intel® HD Graphics 4400 + NVIDIA GeForce® GT 730M
  • One of the following displays:
    • 14.0' HD+ TN (1600 x 900)
    • 14.0' FHD IPS (1920 x 1080)
    • 14.0' FHD Touch IPS (1920 x 1080)
  • Up to 12 GB RAM total -- 4 GB soldered to the motherboard + 1 DIMM slot (up to 8 GB DDR3L)
  • One of the following storage options:
    • HDD: 500GB (5400 rpm) + 8GB SSHD, 500GB (7200 rpm) with optional 16GB/24GB M.2 SSD Cache Drive
    • SSD: 128GB SSD SATA3, 180GB SSD OPAL, 240GB SSD OPAL, 256GB SSD eDrive (OPAL 2.0), 512G SSD SATA3
  • One of the following WLAN + Bluetooth adapters:
    • Intel® Centrino® 7260 (Wilkins Peak 2 AC) 2x2 AC+ BT 4.0
    • ThinkPad Wireless 2x2 BGN+BT 4.0
  • One of the following WWAN adapters (optional):
    • Ericsson N5321
    • Sierra EM7345
  • Fingerprint Reader - Validity Sensors, Inc. 138a:0017
  • Battery
    • Integrated 3-cell 23.5 Whr + External 3-cell 23.5Whr (Thinkpad Battery 68)
    • Integrated 3-cell 23.5 Whr + External 6-cell 47.5Whr
    • Integrated 3-cell 23.5 Whr + External 6-cell 72Whr (Thinkpad Battery 68+)
  • 3x USB 3.0 connectors (one of them always on)
  • 1x VGA (maximum resolution 2048x1536) (Ref: http://download.lenovo.com/ibmdl/pub/pc/pccbbs/mobiles_pdf/t440s_ug_en.pdf page 37)
  • 1x Mini DisplayPort (maximum resolution 2560x1600)
  • 1x Stereo headphone / microphone combo audio port (4-pin TRRS connector with CTIA standard pinout, details: http://pinoutsguide.com/HeadsetsHeadphones/samsung_moment_pinout.shtml)
  • Docking connector (supports ThinkPad Ultra Dock, ThinkPad Pro Dock, ThinkPad Basic Dock)
  • Size: 20.6 x 331 x 226 mm ( = 0.81 x 13.03 x 8.9 in)
  • Weight: 1.56 kg ( = 55.03 oz / 3.44 pounds)

Resources

Pages in category 'T440s'

The following 18 pages are in this category, out of 18 total.

B

D

E

H

L

P

T

T cont.

V

Retrieved from 'https://www.thinkwiki.org/w/index.php?title=Category:T440s&oldid=58391'

The Lenovo ThinkPad T440s is one of the best business laptops that you can buy. It has a strong build quality, serious styling, but most importantly, good speed, an excellent keyboard, and plenty of features. However, there is also a T440 (non ‘s’) model available, too. This is more of a low-cost option and we’ve outlined the differences between the two models below, just to make it a little easier for you to device which one to buy.

Processor speed: The ThinkPad T440 is available in a slower speed than the ThinkPad T440s. While both laptops are available with Intel Core i5-4300U and Intel Core i7-4600U processors, the T440 can also be bought with a slower Core i5-4200U processor.

Graphics: Both use Intel HD 4400 graphics that are built in to the processor.

Thinkpad

RAM: Both the ThinkPad T440 and the ThinkPad T440s support up to 12GB of RAM. One memory slot can house up to an 8GB module, and there is also 4GB soldered onto the motherboard. The low end T440 doesn’t have on-board memory, relying solely on the memory slot.

Thinkpad T440s Ram Slots 1tb

Storage: Both the ThinkPad T440 and the ThinkPad T440s are available with a selection of hard drives and solid state drive options. Hard drives of 500GB (7200rpm) and 1TB (5400rpm) capacities are only available on the low-cost models, while a solid state drive up to 512GB can be selected in the most expensive models. The T440s also features hybrid storage in which the hard drive is aided by a 16GB mSATA solid state cache drive.

Thinkpad T440s Ram SlotsThinkpad t440s ram slots 1tb

Screen: The T440s is available with a better screen that uses IPS technology and has a Full HD, 1920x1080 resolution. The T440 has a starting resolution of 1366x768 and is available up to 1600x900. Both models come with a 720p webcam.

Touchscreen: Both the ThinkPad T440 and the ThinkPad T440s are available with a touchscreen, though the touchscreen resolution on the T440 is 1600x900 and the resolution of the touchscreen on the T440s is 1920x1080.

Thinkpad T440s Ram Slots

Ports: The T440 and T440s both have Mini DisplayPort with audio, VGA, Gigabit Ethernet, and a full-sized SD card reader. However, the T440 only has two USB 3.0 ports compared to the T440s, which has three USB 3.0 ports, and the T440s also has a docking connector.

Wireless: Both the T440 and the T440s are available with either 802.11n or 802.11ac wireless networking (with 2x2 antennas), and with Bluetooth 4.0.

Weight: The starting weight of the T440 is a little heavier than the T440s. The T440 starts at 1.8kg, while the T440s starts at 1.59kg.

Dimensions: The ThinkPad T440s is a little bigger than the T440s. The T440 has dimensions of 339x232.5x21mm (width x depth x height), while the T440s has dimensions of 331x226x20.65mm.

Other common business features: Both the T440 and the T440s are available with mobile broadband, a fingerprint reader, a Smart Card reader, a touchpad and TrackPoint, a backlit keyboard, and two batteries (one internal and one external).

If you want more information on the Lenovo ThinkPad T440s, be sure to check out our article on the research and development that led to the creation of the latest model.
